Product description:
8300 PE polyester baking fish is made of high-quality oil-free alkyd resin and other organic resins and on-poisonous pigment and refined by advanced prescription process with such characteristics as rapid drying, convenient construction, plump, smooth and bright paint film, high harness, high elasticity, good weather fastness, heat and cold resistance, capacity for disinfection in boiling water, boiling resistance, and resistance to corrosion by ordinary chemicals and etc. The baking finish is widely applied for the metallic surface finish of automobile, bicycle, household appliances, engineering machinery, toys and various package tanks and etc.
Application scope:
Surface finish of various metals, alloys, nonferrous metals and other temperature-resistant materials
Physicochemical parameters:
|
No. |
Item |
Standard |
Index |
|
1 |
Viscosity |
GB/T1723-93 |
80-85KU/25¡æ |
|
2 |
Specific gravity |
GB/T6750-86 |
1.00-1.30(depend on different colors) |
|
3 |
Solid content |
GB/T1725-79 |
¡Ý55-65%£¨Depend on different colors) |
|
4 |
Color of appearance |
GB/T9761-88 |
The paint film is flat and smooth, and the color is reasonably consistent with the sample. |
|
5 |
Thickness of film |
GB/T13452.2-92 |
25¡À2¦Ìm(Dry film) |
|
6 |
Gloss |
GB/T1743-79£¨600£© |
Specular to flat, highlight ¡Ý850 |
|
7 |
Adhesion |
GB/T9286-88 |
Zero grade (tinplate) |
|
8 |
Hardness |
GB/T6739-86 |
¡Ý2H (pencil made by Japan Mitsubishi) |
|
9 |
Flexibility |
GB/T6742-86 |
3mm rod without crack |
|
10 |
Impact resistance |
GB/T1732-93 |
¡é12.5mm*500g*50cm positive and negative impact without crack |
|
11 |
Salt fog resistance |
GB/T1771-91 |
¡Ý48H |
|
The type of selected pigment shall conform to 2002/95EC (RoHS) 2005/618/EC and EPA3540C/EPA3550C standard. | |
